The Fidas® 200 fine dust monitor uses the recognized measuring technique of optical light scattering according to ISO 21501-1 on the single particle and is equipped with an LED light source of high light intensity, high light stability, and long service life. The instrument’s calibration can be easily and quickly checked and, if necessary, adjusted at any time, even when installed, using a monodisperse test aerosol.
The sampling system of the Fidas® 200 operates with a volume flow of approx. 0.3 m3/h.
It is equipped with a Sigma-2 sampling head according to VDI 2119, which enables representative sampling even in strong winds, as well as a drying section, which demonstrably prevents falsification of the measurement due to condensation effects at high humidity.
Categories:
Have questions? Call +61 2 9622 6327
| Measuring principle | Optical light scattering at single particles |
| Reported data | PM1, PM2.5, PM4, PM10, TSP, CN, particle size distribution, ambient pressure, ambient temperature, rel. ambient humidity |
| Measurement range (number CN) | 0–20,000 particles/cm³ |
| Measurement range (size) | 0.18–18 µm (certified range, other measuring ranges on request) |
| Measurement range (mass) | 0–10,000 µg/m³ |
| Measurement uncertainty | 9.7% for PM2.5, 7.5% for PM10 (expanded measurement uncertainty according to EN 16450, TÜV Report) |
| Volume flow | 4.8 l/min ≙ 0.3 m³/h ± 3% (24h), compliant with EN 16450 |
| Size channels | 64 (32/decade) |
| Time resolution | 1 s–24 h |
| Interfaces | USB, Ethernet (LAN), RS-232, Wi-Fi |
| User interface | Touchscreen, 800 × 480 pixel, 7″ (17.78 cm) |
| Protocols | UIDEP, UDP, ASCII, MODBUS, Bayern-Hessen |
| Data logger storage | Capacity for 2 years continuous operation at 60 s storage interval |
| Software | PDAnalyze |
| Data acquisition | Digital, 20 MHz processor, 256 raw data channels |
| Light source | Long term stable LED |
| Housing (Gehäuse) | Table housing, optional: with mounting brackets for rack-mounting |
| Operating system | Windows 10 IoT Enterprise |
| Power supply | 115–230 V, 50/60 Hz |
| Installation conditions | +5–+40 °C |
| Response time | < 2 s |
| Sampling head (Probenahmekopf) | Passive collector Sigma-2 |
| Dimensions | 450 × 320 × 180.5 mm (H × W × D), 19″ |
| Weight | Control unit: 9.3 kg, sample head: 2.25 kg, sample tube: 4.5 kg |
| Sampling system (Probenahmesystem) | Drying of the aerosol by IADS (Intelligent Aerosol Drying System) |
| Noise emission | < 70 dB(A) |
| Fuse | T2A |
| Resolution | 0.1 µg/m³ |
| Power consumption | Normal operation: 60 W, max. 200 W |
| Data management | Prepared for connection to the Palas Cloud MyAtmosphere (“MyAtmosphere-ready”); Internet access and separate registration required. The MyAtmosphere terms of use apply. |
Talk to our sales team. Call +61 2 9622 6327
The Particles Plus® 10000 is designed for outdoor particulate and gas monitoring. These robust monitors provide reliable, accurate measurement of airborne contamination allowing for the detection of environmental and public health concerns. The first real time monitor to provide 6 accurate particulate size channels. Realtime Data 6 particle size channels recorded by the 10000 Monitor are stored in an internal non-volatile memory at user-defined data sampling rates (1 second to -99 hours). The high time-resolution of the Model 10000 measurements provides a near-instantaneous look at changing airborne particulate concentrations, leading to a well-defined model of local point source influences that may disproportionately affect air quality. Internet-Enabled Particles Plus® systems are configured to allow users to push real-time data to the cloud where sensor outputs can be visualized by authorized stakeholders. Fully Integrated Low-Cost Air Quality Sensor System Integration of additional sensors for measurement of environmental and meteorological parameters (relative humidity, temperature, barometric pressure, (optional) carbon dioxide – CO2, and total volatile organic compounds – TVOC) offers a more complete view of air quality.
AQ Guard Smart 1000 is a compact and cloud-enabled air quality measurement device.
Cairnet® device is a real-time standalone and networkable air-monitoring station including up to six Cairsens® microsensors. It is powered by solar panels and offers cellular communication.
The 11000 is a low cost, high-accuracy dust monitor designed for outdoor particulate and gas monitoring. These robust monitors provide reliable, accurate measurement of airborne contamination allowing for the detection of environmental and public health concerns. The first real time monitor to provide 30 accurate particulate size channels at higher concentrations.
